1 TEST PROGRAMS AND ADJUSTMENTS32 / 266
Display program no. 8:
Measurement values for activation of the sine-wave generator.
AUTO CUT, AUTO COAG 1 and 2 in SOFT mode, AUTO BIPOLAR
Output measurement value U
act
Display for ICC 350 and ICC 300:
AUTO CUT AUTO COAG 1 AUTO COAG 2 AUTO BIPOLAR
ppp uuu cos PU
ppp HF power output [W], present power output
uuu HF output voltage [V], present output voltage
cos cos-j-value from the table (ICC 350 only)
PU Abbreviation of the test title (Power and voltage measurement)
Display program no. 8
Display program no. 8:
Measurement values for activation of the sine-wave generator.
AUTO CUT, AUTO COAG 1 and 2 in SOFT mode, AUTO BIPOLAR
Output measurement value U
act
Display for ICC 200:
AUTO CUT AUTO COAG
ppp P
ppp HF power output [W]
P Abbreviation of the test title (Power measurement)
