TB100 and TB130 Top Bender Features
● Ideal for producing consistent quality bends in pipe, tube, squares, solids and other
profiles
● Touch screen control offers easy access to auto and manual operating modes,
programming (inch or metric), system diagnostics and multiple language capability
● Quick-change tooling system with multiple radii available
● Digital display of bend angle
● Bend any angle to 180° with independent material springback compensation for each
bend
● Hand-held control of bend, return and emergency stop functions
● Swing away counterbending die vise for easy material handling
● Counterbending die vise position monitored electronically for accuracy and repeatability
● Two axis positioning table for multiple and sequential bends available on special request
● Heavy-duty steel gear case
● No hydraulic components
TB100 and TB130 Top Benders
Capacities and Specifications
TB100 TB130
Tube (Min.) ¼″ ¼″
(Max.) 4″ 5″
Pipe (Max.) 3″ Sch. 40 4″ Sch. 40
Centerline Radius (Min.) 2 x Ø 2 x Ø
(Max.) 17″ 27½″
Degree of Bend 0-210° 0-210°
Bending Speed Variable to 1.3 RPM Variable to .75 RPM
Programming Touch screen Touch screen
Unlimited storage with USB Unlimited storage with USB
(12) bends per program (12) bends per program
Material Positioning Table Consult factory Consult factory
Voltage 220V or 440V 3ph 220V or 440V 3ph
Length, Width, Height 20″ x 34″ x 47″ 34″ x 34″ x 47″
Weight 1,030 lbs. 1,330 lbs.
All capacities based on A53 grade A 48,000 psi tensile materials; heavy wall and high tensile materials reduce machine capacity.
Consult supplier for material specifications.
