– 82 –
Tooling for Pipe
*Part# 050E required when bending radii 225mm and larger. (Not required for TB100/TB130/TB180.)
All standard Ercolina counterbending dies are provided in bronze.
Pipe Outside Wall Thickness Minimum CLR Drive Center Former Counterbend Die
Size Diameter
Sch. / Inches Inches / Millimeter Diameter Part# Part#
¼″ .540 40 .088 1.4 36 153R036P0250 155P0250
⅜″ .675
40 .091 1.4 36 153R036P0375
155P0375
10 .065 2.2 56 153R056P0375
40 .109 1.8 46 153R046P0500
½″ .840 10 .083 2.2 56 153R056P0500 155P0500
5 .065 2.6 67 153R067P0500
40 .113 2.2 56 40mm 153R056P0750
¾″ 1.050 10 .083 2.6 67 153R067P0750 155P0750
5 .065 3.2 82 153R082P0750
40 .133 2.6 67 153R067P1000
1″ 1.315 10 .109 3.2 82 153R082P1000 155P1000
5 .065 4.4 112 153R112P1000
40 .140 3.5 90 153R090P1250
40 .140 3.9 100 153R100P1250
1¼″ 1.660 10 .109 5.1 130 153R130P1250 155P1250
5 .065 5.9 150 153R150P1250
5 .065 7.5 190 153R190P1250
40 .145 3.9 100 153R100P1500
40 .145 5.1 130 153R130P1500
1½″ 1.900 40 .145 5.9 150 50mm 153R150P1500 155P1500
10 .109 6.7 170 153R170P1500
5 .065 7.5 190 153R190P1500
40 .154 5.1 130 153R130P2000
10 .109 5.9 150 153R150P2000
2″ 2.375
5 .065 7.5 190 153R190P2000
155P2000
5 .065 8.9 225 157R225P2000
5 .065 10.2 260 157R260P2000
5 .065 11.8 300 157R300P2000
2″ 2.375
5 .065 10.2 260 80mm 157R260P2000-80
155P2000
5 .065 11.8 300 80mm 157R300P2000-80
40 .203 9.8 250 157R250P2500*
2½″ 2.875 10 .120 10.2 260 50mm 157R260P2500* 155P2500
5 .083 11.8 300 157R300P2500*
10.2 260 80mm 157R260P2500-80
2½″ 2.875 40 .203 11.8 300 80mm 157R300P2500-80 155P2500
13.8 350 80mm 157R350P2500-80
11.8 300 80mm 157R300P3000-80
3″ 3.500 40 .216 11.8 300 110mm 157R300P300-110 155P3000
13.8 350 80mm 157R350P3000-80
4″ 4.500 40 .237 13.8 350 110mm 157R350P400-110 152BP4000
80mm and 110mm drive diameters available for TB100 and TB130
03/2015TB100/TB130
