Tooling for Round Tube
- Continued on next page -
Tube Outside Wall Minimum CLR Drive Center Former Counterbend Die
Size Diameter Thickness
Inches / Millimeter Diameter Part# Part#
¼″ .250 .035 1.4 36 153R036T0250 154T0250
⅜″ .375 .035 1.4 36 153R036T0375 154T0375
½″ .500 .035 1.4 36 153R036T0500 154T0500
⅝″ .625
.083 1.4 36 153R036T0625
154T0625
.035 1.8 46 153R046T0625
.083 1.8 46 153R046T0750
¾″ .750 .065 2.2 56 153R056T0750 154T0750
.035 2.6 67 153R067T0750
.083 1.8 46 153R046T0875
⅞″ .875 .065 2.2 56 153R056T0875 154T0875
.035 2.6 67 40mm 153R067T0875
.083 2.2 56 153R056T1000
1″ 1.000 .065 2.6 67 153R067T1000 154T1000
.035 3.2 82 153R082T1000
.095 2.2 56 153R056T1125
1⅛″ 1.125 .083 2.6 67 153R067T1125 154T1125
.035 3.2 82 153R082T1125
.095 2.6 67 153R067T1250
1¼″ 1.250 .083 3.2 82 153R082T1250 154T1250
.035 4.4 112 153R112T1250
1⅜″ 1.375
.083 3.2 82 153R082T1375
154T1375
.035 4.4 112 153R112T1375
.109 3.5 90 50mm 153R090T1500
1½″ 1.500 .083 3.9 100 50mm 153R100T1500 154T1500
.083 4.4 112 40mm 156R112T1500
.065 5.1 130 153R130T1500
1½″ 1.500
.049 5.9 150 153R150T1500
154T1500
.035 6.7 170 156R170T1500
.035 7.5 190 153R190T1500
.109 3.5 90 153R090T1625
.083 3.9 100 153R100T1625
1⅝″ 1.625
.065 5.1 130 50mm 153R130T1625
154T1625
.049 5.9 150 153R150T1625
.035 6.7 170 156R170T1625
.035 7.5 190 153R190T1625
.109 3.9 100 153R100T1750
1¾″ 1.750 .095 5.1 130 153R130T1750 154T1750
.095 5.9 150 153R150T1750
TB100/TB13003/2015
