– 84 –
Tooling for Round Tube
*Part# 050E required when bending radii 225mm and larger. (Not required for TB100/TB130/TB180.)
- Continued from previous page -
Tube Outside Wall Minimum CLR Drive Center Former Counterbend Die
Size Diameter Thickness
Inches / Millimeter Diameter Part# Part#
1¾″ 1.750
.065 6.7 170 153R170T1750
154T1750
.035 7.5 190 156R190T1750
.109 3.9 100 153R100T1875
.095 5.1 130 153R130T1875
1⅞″ 1.875 .083 5.9 150 156R150T1875 154T1875
.065 6.7 170 153R170T1875
.035 7.5 190 153R190T1875
.109 4.7 120 153R120T2000
.109 5.1 130 156R130T2000
2″ 2.000 .095 5.9 150 153R150T2000 154T2000
.083 6.7 170 156R170T2000
.065 7.5 190 153R190T2000
.134 4.7 120 153R120T2125
.109 5.1 130 153R130T2125
2⅛″ 2.125 .083 5.9 150 153R150T2125 154T2125
.083 6.7 170 50mm 156R170T2125
.065 7.5 190 153R190T2125
.109 5.1 130 153R130T2250
2¼″ 2.250
.095 5.9 150 153R150T2250
154T2250
.083 6.7 170 156R170T2250
.083 7.5 190 153R190T2250
.109 5.1 130 153R130T2375
2⅜″ 2.375
.095 5.9 150 153R150T2375
154T2375
.083 6.7 170 156R170T2375
.083 7.5 190 153R190T2375
.083 8.9 225 157R225T2500*
2½″ 2.500
.083 9.8 250 157R250T2500*
154T2500
.065 10.2 260 157R260T2500*
.065 11.8 300 157R300T2500*
.156 9.8 250 157R250T3000*
3″ 3.000 .156 10.2 260 157R260T3000* 154T3000
.120 11.8 300 157R300T3000*
3″ 3.000
.156 10.2 260 157R260T3000-80
154T3000
.216 11.8 300 157R300T3000-80
3¼″ 3.250 .216 11.8 300 80mm 157R300T3250-80 152BT3250
3½″ 3.500 .216
11.8 300 157R300P3000-80
155P3000
13.8 350 157R350P3000-80
4″ 4.000 .216 13.8 350 110mm 157R350T400-110 152BT4000
80mm and 110mm drive diameters available for TB100 and TB130
03/2015TB100/TB130
