Ercolina TB100 - Electrical Parts List; Panel Components

– 74 –
- Electrical parts list -
PN Liv. 0 Liv. 1 Description Un Qty
Panel
Complete electric panel 1
TB80-LPFC Plate 1
QS1 STB140-503 Main switch 80A ABB OT80E3 1
QS1 CP8215/A Caps ABB-OTS63T3 1
QS1 STB140-504/1 Shaft 5x180mm ABB-OXS5X180 1
QS1 TP030/A OHY 3AH1 MANIGLIA R/G LUCCHETT 1
FU1 CP8103 Fuse holder.10,3X38 1
FU1 YF093 FUSIBILE 10,3X38MM 20A 3
FU2 CP8103 Fuse holder..10,3X38 1
FU2 YF093 FUSIE 10,3X38MM 20A 3
FU3 CP8102 Fuse holder.BIPOL 10,3X38 1
FU3 CP7127 FUSE 10,3X38MM 2A 2
E1 2866310 ALIM. TRIO-PS/1AC/24DC/5 2866310 1
3RT1026-
KM1 1BB40 Contactor.SIEMENS 11KW24VDC 1
KM1 EN180-416 Additive contact 3RH1921-1EA11 1
E2 SKDD200300 INVERTER COMMANDER 3KW 200/240 1
SMARTSTICK SMARTSTICK for COMMANDER SKCD200220 1
KA1 G9SB-2002-C Safety module 1
KA0-
KA4 2966171 Relay PLC-RSC-24DC/21 2
803595 Safety module ZBFM 5/WH:UNBEDRUCKT 5
3040290 Plug ST-COMBI SP2,5/5 5P 2
3040355 Plug ST-COMBI SP2,5/11 11P 2
107-3728 RESISTANCE 250R CONT.ALL.10W 1
KA4- 3RT1017-
KA5 1BB42 Contactor .SIEM.5,5K2 24VDC 2
TP109 Cable “IN”AUTOTRASF.TRIFASE 030 1
TP109A Cable “OUT”AITPTRASF.TRIFASE030 1
