Top Bender Components
Shown below are basic components of a TB100 or TB130 bending machine.
Please take a moment to review this illustration for reference.
8 - Center former
die
1. Hand-held control 6. Counterbending die
2. USB for unlimited program storage 7. Hex shaft
3. Touch screen control 8. Center former die
4. Counterbend die hand wheel 9. Access panel
5. Counterbend die vise 10. Tie bar
9 - Access panel
3 - Touch screen
control
4 - Counterbend die
hand wheel
7 - Hex shaft
6 - Counterbending
die
5 - Counterbend
die vise
2 - USB for unlimited
program storage
1 - Hand-held control
10 - Tie bar
