7-5 MINI-LINK BAS
EN/LZB 111 0542 P2B Technical Description
However, as indicated in the following table, the operator can chose
one out of many possible different configurations.
Configured
mode
Configured
VCI max
Max allowed
VPI
Max possible number of
VCCs at the ET port
255 28160 in 110 VPIs
511 28160 in 55 VPIs
767 27648 in 36 VPIs
1023 27648 in 27 VPIs
1279 28160 in 22 VPIs
1535 27648 in 18 VPIs
1791 26880 in 15 VPIs
2047 26624 in 13 VPIs
3583 25088 in 7 VPIs
4607 27648 in 6 VPIs
6655 26624 in 4 VPIs
9215 27648 in 3 VPIs
NNI
16383
4095
16384 in 1 VPI
255 30976 in 121 VPIs
511 30720 in 60 VPIs
767 30720 in 40 VPIs
1023 30720 in 30 VPIs
1279 30720 in 24 VPIs
1535 30720 in 20 VPIs
2047 30720 in 15 VPIs
3071 30720 in 10 VPIs
4095 28672 in 7 VPIs
7679 30720 in 4 VPIs
14335 28672 in 2 VPIs
UNI
16383
255
16384 in 1 VPI
Within those constraints, the operator has full freedom to choose any
combination of VPI and VCI values, thus enabling the use VPI values
in accordance to one of the policies.
For example, the operator may decide to use the same VPI for all the
connections that must extend over the ATM network towards the same
destination node, so that they can be cross-connected as a single VPC.
