8.7.2 Rear Access Central Office
The rear access shelves are primarily intended to be mounted in
ANSI/EIA-310 compliant 19" or 23" equipment frames. Those types
of racks are not included in the MINI-LINK BAS.
The rear access system will be delivered on a shelf level. MINI-LINK
BAS with rear access shelves must be deployed in racks accessible
from the back, a possible configuration in 7’ racks, 19" or 23", is
shown below.
PDU
PDU
R-AAS
R-AAS
R-AAS
C-AAS
(CE Shelf)
CP
Figure 8-16 Typical US Central Office
