MINI-LINK BAS 9-14
Technical Description EN/LZB 111 0542 P2B
Unit Name LED Colour Status Function
Power Green On Power on
Fail Red On HW fail or if
LI1 and LI2 LED are ON too, the board
is unmanaged
LI 1 Yellow On Port successfully connected
(no meaning on PVC)
LI 2 Yellow On Port successfully connected
(no meaning on PVC)
SU 10/100BaseT
Blue On Board inserted but no active (ready to
be removed)
FlexNU,
Power Supply
Power Fail Red On Power Fault
Power Green On Power On
POU
Fault Red On Power fail on POU (if the LED Power is
ON too), or
loss of input power (if only this LED is
ON)
Power Green On Power on
PSU
Fault Red On Power fail on PSU (if the LED Power is
ON too), or
loss of input power (if only this LED is
ON)
Power Green On Power On
ET, CE units
Fault Red On HW Fail or
restart/SW download on going
(no contact with CP)
Power Green On Power On
Fault Red On HW Fail or
restart/SW download on going
(no contact with CP)
Power Modem Green On Modem is powered On
NCU units
Fault Modem Red On HW fault or
missing connection with the radio
(HDLC down)
CP Run Green On Power On
