MINI-LINK BAS 6-8
Technical Description EN/LZB 111 0542 P2B
• VCI = 31 + 2 = 33
To address a board in slot 4 of the R-AAS number 42, the VPI/VCI
output from the CP is:
• VPI = 1
• VCI = 31 + 4 = 35
In case of local CP configurations the ICS connections
are automatically set by the CP and by the ET located
in slot 1 of the first level shelf.
