SECTION 2 DESCRIPTION
2.1 General
As shipped, the ESP-101 is fully assembled and ready to cut after being connected to input power, a source of
compressed air, and a PT-37 torch. The ESP-101 system uses the heavy-duty PT-37 (Mechanized Plasma) torch to
deliver cutting power for cutting materials up to 1-1/4 inch (32 mm) thick. Refer to the following pages for de-
scriptions of the ESP-101 packages available as well as performance specications.
2.2 Scope
The purpose of this manual is to provide the operator with all the information required to install and operate the
ESP-101 Plasma Arc Cutting System. Technical reference material is also provided to assist in troubleshooting the
cutting system.
USE THE ESAB PT37 PLASMARC TORCH WITH MECHANIZED CON
SOLES. USE OF TORCHES NOT DESIGNED FOR USE WITH THIS CON
SOLE COULD CREATE AN ELECTRIC SHOCK HAZARD.
