30
BEFORE MAKING ANY CONNECTIONS TO THE POWER SOURCE OUT
PUT TERMINALS, MAKE SURE THAT ALL PRIMARY INPUT POWER TO
THE POWER SOURCE IS DE ENERGIZED OFF AT THE MAIN DISCON
NECT SWITCH.
CLAMP THE WORK CABLE TO THE WORK PIECE. BE SURE THE WORK
PIECE IS CONNECTED TO AN APPROVED EARTH GROUND WITH A
PROPERLY SIZED GROUND CABLE.
Figure 3-6. ESP-101 Interconnection Diagram
SECTION 3 INSTALLATION
F14-080 A
May, 1999
Installation, Operation, and Maintenance Manual for the
SHADOW
GANTRY SHAPE CUTTING MACHINE
411 S. Ebenezer Road
Florence, SC 29501-0545
PT-37
Torch Cable
CNC Control Cable
(back connection)
SAFETY GROUND
3.8 Secondary Output Connections for Mechanized Cutting
WARNING
WARNING
