ESAB ESP-101 - CNC Interface Connection

27
SECTION 3 INSTALLATION
Figure 3-5. Mechanical Cutting Interface Diagram CNC Interface Connection
3.6 CNC Interface Connection
Front View
Note:
If replacing the ESP-100 with an ESP-101, reversing wires 1 and 2 on the CNC cable may be necessary for proper polarity.
Power Source
CNC
ESP-101
(+)
(-)
START
MOTION
ALLOW
FOR AUTOMATIC
HEIGHT CONTROL
OPTIONAL
INPUT
EXTERNAL
CURRENT
COMMAND
CORNER
EXT REF
#11
START
COMMON
CORNER / EXT REF
FAULT
ARC ON COMMON
ARC ON
VDR +
VDR 
#13
#14
#5
#6
#1
#2
#7
#9
#3
#8
M
N
E
F
A
B
G
I
C
H
J64 GRN
J61 BLU
J66 WHT
J67 BRN
J61 RED
J25 VIO ARC ON
J26 WHT ARC ON
J12 ORN
J13 GRY
M
N
E
F
A
B
G
I
C
H
K K
CURRENT REF +
CURRENT REF 
#12
#10
L
J
J41 YEL
J42 BLK
L
J
#4
D D
OPTIONAL
REMOTE
CURRENT
CONTROL
ACTIVE
DRIVER
START
COMMON
CORNER / EXT REF
+1230 VDC FAULT SUPPLY
