56
RECOMMENDED TORQUES ( IN/LBS ±10% )
SYMBOL / DESCRIPTION MOUNT TERMINAL
BR101 36 36
Q2,3 32 32
D4,5 28 22
C5,6 - 25
C11,12,13,14 - 18
R1,2,3,4,5,6,7 6 -
R14 Hand -
SW1 22 35
K1 18 40
K2 18 18
F1 , TB1 14 -
TS1 , J1 , TEE 12 -
SOL1 10 -
HEATSINK 28 -
M1,2 18 -
JP1 36 36
WORK , GND1 44 44
GND2 12 -
PCB1,2 10
PCB1 - J12 - 12
PCB3 - POTENTIOMETERS 14 -
PCB4 14 -
PCB4 - P1,2 - 44
PCB4 - P3 - 25
PCB5 - TB1,2,3,4,9,10 - 44
PCB5 - TB6,8 - 25
PCB6 10 -
PCB7 18 14
P7,8 - 2.5
P1,2,3,4,6,7,9,13,16 - 4.5
STANDOFFS 7 -
HANDLES 44 -
SHEETMETAL #8 18 -
SHEETMETAL #10 28 -
SHEETMETAL 1/4" Impact -
7.3 Torque Recommendations
SECTION 7 REPLACEMENT PARTS
