Chapter 3 Operation Instructions SuZhou Eshine Elevator Components Co., Ltd.
―8― YS-K01 Door Controller User Manual
The LED panel of controller has 4-digit LED digital tubes and the meanings are shown as Table
3-2.
Table 3-2 Digital tube display description
LED display Meaning LED display Meaning LED display Meaning LED display
Meaning
0
A
J
U
1
b
L
u
2
C
n
y
3
c
o
－
4
d
P
Point
5
E
q
All display
6
F
r
No display
7
H
S
Flashing
changeable
8
h
T
9
i
t
The YS-P01 panel has 1 state indicator and 3 unit indicators whose meanings are shown as
Table 3-3.
Table 3-3 Description of indicator of LED panel
Identification
Name Light color Description
Running state
indicator
Green
On: It represents the controller is at running state
Off: It represents controller isn’t at running state
Frequency unit
indicator
Green The present unit indicator is frequency
Current unit
indicator
Green The present unit indicator is current
Voltage unit
indicator
Green The present unit indicator is voltage
&
Percentage unit
indicator
Green
Hz and V is on simultaneously, and the present
unit indicator is percentage
The indicator has two states off and on. In the manual the identification is as follows:
The indicator is off; The indicator is on.
