Page 148 Fire Alarm
Computer 8000C
According to the configuration of the FACP 8000C, the following primary loop numbers are
possible:
Basic module (Panel no. 01)
Primary loop
number
subassembly
0111 common trouble relay of the basic module
0112 interface of the basic module
0113 micro module slot of the basic module
Field device module in slot 1 (Panel no.
01)
Primary loop
number
subassembly
0121 relays K2, K3 and K4 of the field device module
0122 master box relay of the field device module
0123 micro module slot of the Field device module
0124 internal primary loop of the Field device module
Extension module in
slot
1 (Panel 01)
Primary loop
number
subassembly
0121
no module available
0122
no module available
0123 micro module slot of the extension module
0124
no module available
Commissioning / Servicing
