Page 76
Fire Alarm Computer 8000C
10.4 Definition of the Primary loop number
Individual subassemblies of the FACP 8000C can be switched on/off with the internal primary line
number via the central keyboard or also programmed with the customer data editor. This internal
primary line number is composed of the central unit number, the slot and the subassembly
number.
0 1 2 3
Subassembly number of the Basic-, Field device- oder extension
modue
Slot no.: Basic modue = no. 1
Basic modue slot 1 = no. 2
Basic modue slot 2 =
without function
Number of the Fire Alarm Panel (01 to max. 31)
Basic module (Panel no. 01)
Primary loop
number
subassembly
0111 common trouble relay of the basic module
0112 interface of the basic module
0113 micro module slot of the basic module
Field device module in slot 1 (panel no. 01)
Primary loop
number
subassembly
0121 relays K2, K3 and K4 of the field device module
0122 master box relay of the field device module
0123 micro module slot of the Field device module
0124 internal primary loop of the Field device module
Extension module in slot 1 (Panel 01)
Primary loop
number
subassembly
0121
no module available
0122
no module available
0123 micro module slot of the extension module
0124
no module available
Peripheral modules or extension modules may only be installed in
slot 1
of the basic
module.
Slot 2
of the basic module is inoperative on the 8000C FACP. No modules may
inserted into
slot 2
.
Location of plug in cards
