Fire Alarm Computer 8000C
10.6 Basic module of the FACP 8000C
Fig. 37: Basic module
Replacing the operating system software
When replacing the operating system software (EPROM D6+D7), the customer data is
automatically deleted. Before changing the EPROM, save your data on the hard disk of the service
PC. After installing the new operating system software, the customer data can be transferred back
from the service PC to the FACP 8000C.
!
Warning: Danger of explosion in case of inappropriate replacement of the 3V/270 mA
battery!
Only use an identical battery or a type recommended by the manufacturer. Used batteries
should be disposed of observing the recommendations of their manufacturer.
Basic module
Printer
X21 X20
GND +UB
ext.
transformator
terminals
NPEL1/U
mains 230V~
X19
X18
X11 X12 X13 X14
micro module
RxD TxD
TTY
GÖ
S
SaS
1
1
1
2
1 2 3 4 5 6 7 8
F1
T630mA
Slot for micro module
Slot for power supply module
X110
Battery
3V/270mAh
Basic module
S1
Reset
+
-
X17 X16
Battery 1
Battery 2
PE
BR4
D5
D6 D7
V41V42
Operating modulel
X7
X10
Printer connection
V31
V33
send
LED
Polatiry
reversal
indication
Plug 2 Plug 1
X15
D4
V43
BR5 BR6 BR7
A B A B A B
RS
485
S5
X22 X23
1 2 3 4 5 6 7 8
D29
BR1
F2
T2A
battery jumper
F3
battery 1
T2,5A
F4
battery 2
T2,5A
X8
+
-
+
-
1 2 3 1 21 2 31 2 3
BR2
Printer
1
DK
