Esser FACP 8000C - Primary Loop Functions Management

Fire Alarm Computer 8000C
Page 41
5.1.1 Primary loop functions
Using this function, primary loops including all connected detector zones and detectors can be
switched on or off at the keypad.
The switching state is indicated on the control panel and the alphanumeric display.
Fig. 44: Entering the primary loop number
♦
all analogue ring loop modules included in this FACP
(including the analogue ring loop with all associated devices connected to this module)
♦
all 4-zone-modules included in this FACP
(including all detector zones and detectors connected to this module)
♦
certain modules such as relays or the interface on the basic/peripheral module
Definition of primary loop numbers
The four digit primary line number is determined by the slot number of the corresponding micro
module or of the module within the 8000C FACP and by the FACP number. The peripheral and
extension module is always located in
slot 1
of the basic module. Operation in any other slot is not
possible.
0 1 2 1
Slot number of the Basic-, Field device or Extension module
Slot number: Basicmodule = No. 1
Basicmodule
Plug 1
= No. 2
No. of the Fire Alarm Control Panel (max. 31)
Example: A non-networked single FACP (no. 01) has an analogue ring loop module plugged into
the peripheral module (module slot 3). This configuration has the primary line number
0123 (ref. section 10.4).
Service Level
Primary loop / Transfer route
Primary loop :
Func. menu Repeat Select
1 on / off
2 reset
