Esser FACP 8000C - Analog Ring Loop Testing

Page 150 Fire Alarm
Computer 8000C
25.1.2 Testing (the analog ring loop)
Fig. 7: Testing the analog ring loop
♦
Enter the number of the analog ring loop to be tested and press the
Select
function key.
♦
Enter the number of the desired function (3 = Testing) or select the menu point
Test operation
with the cursor keys and press the
Function
key
!
An analog ring loop in test operation will not signal an alarm in the case of an event !
The Function Testing is not carried out when ...
♦
the analog ring loop is switched off.
♦
the analog ring loop module is defective.
Testing an analog ring loop
The test operation must be carried out individually for each analog ring loop or detector zone. The
simultaneous testing of several analog ring loops/detector zones is impossible.
By this menu point, the selected analog ring loop (including all detectors and esserbus
®
transponders) or single detector zones in the analog ring loop are tested for the following
functions:
♦
Malfunctions of one or more detectors / esserbus
®
transponders.
♦
Malfunction of the switch-on control (SOC) by automatic detectors.
♦
Conformance of the addresses with the Customer data programming
(if necessary, the detector data is automatically updated).
♦
Conformance of the ring loop wiring with the Customer data programming.
♦
Conformance of detector types and external wiring with the Customer data programming.
Commissioning / Servicing
Primary loop / transfer route
Primary loop : 121
Escape Function
1 Switch on / reset
2 Switch off
3 Test
4 Replace detector
