Page 152 Fire Alarm
Computer 8000C
Fig. 8: Flow diagram of detector replacement
Commissioning / Servicing
At the control panel
Using the table on next page,
find out whether the replacement can be carried out
without the service PC.
At the control panel
no
yes
At the location
of the detector
Wait until the display "TEST"
for the primary loop go out.
Have malfunctions occurred?
no
Replacement of detectors is completed.
yes
Check the execution of the
replacement and reactivate
Replace detector function.
Switch the primary loop, detector
zone or detector. Replacement
of detectors is completed.
connect service-PC and
carry out automatic wiring
analog ring loop.
Enter the installation code, select primary loop
function, enter the primary loop number and select
function 4 "replace detector".
On the primary loop all zones and the Primary loop
are indicated on the display with "TEST"
Which trouble code appears
in the display ?
see section 11 (detector malfunctions).
no
yes
Exchange all detectors which are to be replaced in the
analog ring loop. Screw the new detectors tightly into
the detector bases, do not damage connecting cables.
Enter the installer code, select primary loop function,
enter the primary loop number and
select function 2 "swich off"
Is this malfuntion
due to the replacement
of detectors?
