Esser FACP 8000C - Housing and Battery Configurations

Fire Alarm Computer 8000C
Page 59
Housing with operating front, printer, additional housing with neutral front and 2 x battery 12V /
24Ah
123
456
789
0
Fig. 15: Housing variant FACP 8000C
Housing with operating front, printer, additional housing for 2 x battery 12V / 24Ah and single zone
indicator unit (192 zones)
123
456
789
0
Fig. 16: Housing variant FACP 8000C with single zone indicator unit (192 zones)
Configuration options
