User’s Manual
134 ECM-3610/3610L User’s Manual
Appendix B: System Resources
Memory Map
The following table indicates memory map of ECM-3610. The address ranges specify the
runtime code length.
Address Range Description Note
00000000h-0009FFFFh System board extension for ACPI BIOS
000A0000h-000AFFFFh S3 Graphics Twister
000B0000h-000BFFFFh S3 Graphics Twister
000C0000h-000CDFFFh S3 Graphics Twister
000CE000h-000CFFFFh System board extension for ACPI BIOS
000F0000h-000F7FFFh System board extension for ACPI BIOS
000F8000h-000FBFFFh System board extension for ACPI BIOS
000FC000h-000FFFFFh System board extension for ACPI BIOS
00100000h-06FEFFFFh System board extension for ACPI BIOS
06FF0000h-06FFFFFFh System board extension for ACPI BIOS
E0000000h-E7FFFFFFh PCI standard PCI-to-PCI bridge
E0000000h-E7FFFFFFh S3 Graphics Twister
E8000000h-EBFFFFFFh PCI standard host CPU bridge
EC000000h-EDFFFFFFh PCI standard PCI-to-PCI bridge
EC000000h-EC00FFFFh S3 Graphics Twister
ED000000h-ED07FFFFh S3 Graphics Twister
EE000000h-EE0000FFh Realtek RTL8139/810X Family PCI Fast Ethernet NIC
EE001000h-EE0010FFh Realtek RTL8139/810X Family PCI Fast Ethernet NIC
FEE00000h-FEE00FFFh System board extension for ACPI BIOS
FFFF0000h-FFFFFFFFh System board extension for ACPI BIOS
