User’s Manual
28 ECM-3610/3610L User’s Manual
3.7.14 Signal Configuration – TFT Displays
TFT
Pin name
9-bit 9-bit x 2
12-bit 12-bit x 2
15-bit 15-bit x 2
18-bit 18-bit x 2
24-bit
P35 B12 B13 B14 B15
P34 B2 B02 B3 B03 B4 B04 B14
P33 B11 B12 B13 B13
P32 B1 B01 B2 B02 B3 B03 B12
P31 B10 B11 B12 B11
P30 B0 B00 B1 B01 B2 B02 B10
P29 B10 B11 G15
P28 B0 B00 B1 B01 G14
P27 B10 G13
P26 B0 B00 G12
P25 G11
P24 G10
P23 G12 G13 G14 R5 R05 R7
P22 G2 G02 G3 G03 G4 G04 R4 R04 R6
P21 G11 G12 G13 R3 R03 R5
P20 G1 G01 G2 G02 G3 G03 R2 R02 R4
P19 G10 G11 G12 R1 R01 R3
P18 G0 G00 G1 G01 G2 G02 R0 R00 R2
P17 G10 G11 R11 R1
P16 G0 G00 G1 G01 R10 R0
P15 G10 G5 G05 G7
P14 G0 G00 G4 G04 G6
P13 G3 G03 G5
P12 G2 G02 G4
P11 R12 R13 R14 G1 G01 G3
P10 R2 R02 R3 R03 R4 R04 G0 G00 G2
P9 R11 R12 R13 R13 G1
P8 R1 R01 R2 R02 R3 R03 R12 G0
P7 R10 R11 R12 B5 B05 B7
P6 R0 R00 R1 R01 R2 R02 B4 B04 B6
P5 R10 R11 B3 B03 B5
P4 R0 R00 R1 R01 B2 B02 B4
P3 R10 B1 B01 B3
P2 R0 R00 B0 B00 B2
P1 R15 B1
P0 R14 B0
Note:
The principle of attachment of TFT panels is that the bits for red, green, and blue
use the most significant bits and skip the least significant bits if the display
interface width of the TFT panel is insufficient.
