22 ECM-3610/3610L User’s Manual
3.7 Connector Definitions
3.7.1 Pin Header Serial Port 2 Connector in RS-232 Mode (CM1)
Signal PIN Signal
DCD 1 2 RxD
TxD 3 4 DTR
GND 5 6 DSR
RTS 7 8 CTS
RI 9 10
NC
3.7.2 Serial Port 2 with External DB9 Connector (CM1)
Signal PIN Signal
GND 5
9
RI
DTR 4
8
CTS
TxD 3
7
RTS
RxD 2
6
DSR
DCD 1
3.7.3 Signal Description – Serial Port 2 – COM2 in RS-232 Mode (CM1)
TxD Serial output. This signal sends serial data to the communication link. The signal is set to a
marking state on hardware reset when the transmitter is empty or when loop mode operation
is initiated.
RxD Serial input. This signal receives serial data from the communication link.
DTR Data Terminal Ready. This signal indicates to the modem or data set that the on-
is ready to establish a communication link.
DSR Data Set Ready. This signal indicates that the modem or data set is ready to establish a
communication link.
RTS Request To Send. This signal indicates to the modem or data set that the on-board UART is
ready to exchange data.
CTS Clear To Send. This signal indicates that the modem or data set is ready to exchange data.
DCD Data Carrier Detect. This signal indicates that the modem or data set has detected the data
carrier.
RI Ring Indicator. This signal indicates that the modem has received a telephone ringing signal.
