Evalue Technology ECM-3610 - Network and Floppy Interfaces

ECM-3610/3610L
ECM-3610/3610L User’s Manual 37
3.7.26 10/100BASE-Tx Ethernet Connector (CN10, CN11)
Signal PIN
TXD+ 1
TXD- 2
RXD+ 3
NC 4
NC 5
RXD- 6
NC 7
NC 8
3.7.27 Signal Description – 10/100Base-Tx Ethernet Connector (CN10, CN11)
TXD+ / TXD- Ethernet 10/100Base-Tx differential transmitter outputs.
RXD+ / RXD- Ethernet 10/100Base-Tx differential receiver inputs.
3.7.28 Floppy Connector (FLP1)
Signal PIN Signal
GND 1 2 DRVDEN0#
GND 3 4 NC
GND 5 6 DRVDEN1#
GND 7 8 INDEX#
GND 9 10 MOA#
GND 11 12 DSB#
GND 13 14 DSA#
GND 15 16 MOB#
GND 17 18 DIR#
GND 19 20 STEP#
GND 21 22 WD#
GND 23 24 WE#
GND 25 26 TRAK0#
GND 27 28 WPT#
GND 29 30 RDATA#
GND 31 32 SIDE1#
GND 33 34 DSKCHG#
