Evalue Technology ECM-3610 - DB25 Parallel Port Connector (PNT1)

ECM-3610/3610L
ECM-3610/3610L User’s Manual 41
3.7.38 DB25 Parallel Port Connector (PNT1)
Signal PIN Signal
STB# 1
14 AFD#
PD0 2
15 ERR#
PD1 3
16 INIT#
PD2 4
17 SLIN#
PD3 5
18 GND
PD4 6
19 GND
PD5 7
20 GND
PD6 8
21 GND
PD7 9
22 GND
ACK# 10
23 GND
BUSY 11
24 GND
PE 12
25 GND
SLCT 13
