ECM-3610/3610L
ECM-3610/3610L User’s Manual 27
3.7.13 Signal Configuration – DSTN Displays
STN DSTN
Pin name 8-bit 16-bit 24-bit 8-bit 16-bit 24-bit 16-bit 24-bit
P35
P34
P33
P32 UG2 UG2
P31
P30 UR2 UR2
P29 UB3
P28 UB1 UB1
P27
P26 UG1 UG1
P25 UG3
P24 UR1 UR1 UR1
P23 B7 UR0 UR0
P22 G7 UB0 UB0 UB0 UR1 UR1
P21 R7 UR2 UR2
P20 B6 UG0 UG0 UG0 UR3
P19 G6 UR3 LR0 LR0
P18 R6 UR0 UR0 UR0 LR1 LR1
P17 B5 LR2 LR2
P16 G5 LR3
P15 R5 R5 UG0 UG0
P14 B4 B4 LG2 LG2 UG1 UG1
P13 G4 G4 LB3 UG2 UG2
P12 R4 R4 LR2 LR2 UG3
P11 B3 B3 LG0 LG0
P10 G3 G3 LB1 LB1 LG1 LG1
P9 R3 R3 LG2 LG2
P8 B2 B2 LG1 LG1 LG3
P7 G2 G2 G2 LG3 UB0 UB0
P6 R2 R2 R2 LR1 LR1 LR1 UB1 UB1
P5 B1 B1 B1 UB2
P4 G1 G1 G1 LB0 LB0 LB0 UB3
P3 R1 R1 R1 LB0 LB0
P2 B0 B0 B0 LG0 LG0 LG0 LB1 LB1
P1 G0 G0 G0 LR3 LB2
P0 R0 R0 R0 LR0 LR0 LR0 LB3
