User’s Manual
4 ECM-3610/3610L User’s Manual
Connector
• External Connectors: VGA (DB-15), COM 1 (DB-9), Ethernet (RJ-45) x 2 (ECM-
3610 only), KB/Mouse (Mini-DIN)
• Power Connectors: 4-pin HDD type
Mechanical and Environmental
• Power Supply Voltage: +5V (4.75V to 5.25V), AT/ATX type
• Typical Power Requirement: 5V @ 2.9A (with VIA C3 667MHz CPU)
• Operating Temperature: 32 to 140 °F (0 to 60 °C)
• Board Size: 146mm x 101mm (3.5" FDD-size)
• Weight: 0.4 Kg
