ECM-3610/3610L
ECM-3610/3610L User’s Manual 19
Connectors
Label Function Note
CM1
Serial port 2 connector 5 x 2 header, pitch 2.0mm
CM2
Serial port 1 connector DB-9 male connector
CN1
Secondary LCD panel connector HIROSE DF13-40DP-1.25V
CN2
Primary LCD panel connector HIROSE DF13-40DP-1.25V
CN3, CN4
PC/104 connector
CN5
IDE connector 20 x 2 header, pitch 2.54mm
CN6
CPU fan connector 2 x 1 wafer, pitch 2.54mm
CN7
Audio connector 5 x 2 header, pitch 2.0mm
CN8
CD-ROM audio input connector 4 x 1 wafer, pitch 2.0mm
CN9
IrDA connector 5 x 1 header, pitch 2.0mm
CN10 (LAN1)
10/100Base-Tx Ethernet 1 connector RJ-45
CN11 (LAN2)
10/100Base-Tx Ethernet 2 connector RJ-45 (ECM-3610 only)
DIM1
144-pin SODIMM socket (Real side)
FLP1
Floppy connector 17 x 2 header, pitch 2.0mm
J1
ATX Power connector 3 x 1 wafer, pitch 2.54mm
J2
ATX Soft-power bottom 2 x 1 header, pitch 2.54mm
J3
LCD inverter connector 5 x 1 wafer, pitch 2.0mm
KB1
Keyboard and PS/2 mouse connector 6-pin mini DIN
PNT1
Parallel port connector 13 x 2 header, pitch 2.0mm
PWR1
Auxiliary power connector 4 x 1 wafer, pitch 2.0mm
PWR2
Power connector Molex A-8981-04V5
SN1
Compact Flash connector (Real side)
SW1
Reset button
USB1
USB connector 5 x 2 header, pitch 2.0mm
VGA1
CRT connector DB-15 female connector
VR1
LCD backlight brightness adjustment
connector
3 x 1 header, pitch 2.54mm
VR2
STN LCD contrast adjustment connector 3 x 1 header, pitch 2.54mm
