ECM-3610/3610L
ECM-3610/3610L Users Manual 31
3.7.16.3 Commands
BALE This is an active high signal used to latch valid addresses from the current bus master on the
falling edge of BALE. During DMA, refresh and alternate master cycles, BALE is forced high
for the duration of the transfer. BALE is driven by the permanent master with a totem-pole
driver.
IOR# This is an active low signal driven by the current master to indicate an I/O read operation. I/O
mapped devices using this strobe for selection should decode addresses SA [15:0] and AEN.
Additionally, DMA devices will use IOR# in conjunction with DACK
n
# to decode a DMA
transfer from the I/O device. The current bus master will drive this line with a tri-state driver.
IOW# This is an active low signal driven by the current master to indicate a
n I/O write operation. I/O
mapped devices using this strobe for selection should decode addresses SA [15:0] and AEN.
Additionally, DMA devices will use IOR# in conjunction with DACK
n
# to decode a DMA
transfer from the I/O device. The current bus master will drive this line with a tri-state driver.
SMEMR# This is an active low signal driven by the permanent master to indicate a memory read
operation in the first 1MB of system memory. Memory mapped devices using this strobe
should decode addresses SA [19:0] only. If an alternate master drives MEMR#, the
permanent master will drive SMEMR# delayed by internal logic. The permanent master ties
this line to VCC through a pull-up resistor to ensure that it is inactive during the exchange of
bus masters.
SMEMW# This is an active low signal driven by the permanent master to indicate a memory write
operation in the first 1MB of system memory. Memory mapped devices using this strobe
should decode addresses SA [19:0] only. If an alternate master drives MEMR#, the
permanent master will drive SMEMR# delayed by internal logic. The permanent master ties
this line to VCC through a pull-up resistor to ensure that it is inactive during the exchange of
bus masters.
MEMR# This is an active low signal driven by the current master
to indicate a memory read operation.
Memory mapped devices using this strobe should decode addresses LA [23:17] and SA
[19:0]. All bus masters will drive this line with a tri-state driver. The permanent master ties
this line to VCC through a pull-up resistor to ensure that it is inactive during the exchange of
bus masters.
MEMW#
This is an active low signal driven by the current master to indicate a memory write operation.
Memory mapped devices using this strobe should decode addresses LA [23:17] and SA
[19:0]. All bus masters will drive this line with a tri-state driver. The permanent master ties
this line to VCC through a pull-up resistor to ensure that it is inactive during the exchange of
bus masters.
