EXFO FIP-435B - Page 126

Maintenance
116 FIP-400B
Replacing the Battery
To replace the battery:
1. Turn off the probe.
2. Disconnect any power cable and fibers.
3. Using a screwdriver, remove the two screws that are located on the
side of the probe.
4. Remove the battery compartment door.
CAUTION
Gently pull on the battery to avoid damaging the wires.
Screws
Battery compartment door
