Maintenance
Fiber Inspection Probe 117
Replacing the Battery of the Multifiber Source
5. Remove the battery.
6. Replace the battery, respecting the polarity (black, yellow, and red
wires).
7. Close the battery compartment door.
8. Using a screwdriver, put the screws that you have removed at step 3
back in place.
Replacing the Battery of the Multifiber Source
Your MFS is powered by a Li-ion polymer rechargeable battery.
WARNING
Your unit uses a smart lithium-ion (Li-ion) battery with built-in
protection that has been especially designed for EXFO. For this
reason, you can only replace it with a battery of the same type and
model. You can purchase new batteries from EXFO.
CAUTION
All the components that you should be handling are identified in
the procedure hereafter. Do not touch any other component inside
the unit either with tools or your fingers.
