Analyzing Traces and Events
MAX-700 117
Events Tab
To quickly locate an event in the events table:
1. Ensure that the button is selected in the zoom button bar.
2. Select the event on the trace.
The list scrolls automatically to the event you selected.
Graph
Event no. 1
Event table
Zoom-on-
event button
Event editing buttons
