B Description of Event Types
This section describes all types of events that may appear in the events
table generated by the application. Here is a guide to the descriptions:
Each type of event has its own symbol.
Each type of event is represented by a graph of a fiber trace, which
illustrates the power reflected back toward the source as a function of
distance.
An arrow points to the location of the event type in the trace.
Most graphs show one complete trace; that is, an entire acquisition
range.
Some graphs show only a portion of the entire range to view events of
interest more closely.
