EXFO MaxTester 700 - Generating a Report

Creating and Generating Reports
MAX-700 187
Generating a Report
Generating a Report
You can generate trace reports directly from your unit in HTML format. By
default, only the information related to the active trace is generated in a
report, but you can also generate all the traces the current file contains
(available in Advanced and Auto modes only).
If you want to customize your reports, you can also select the option to
generate them in XML format. The XML file does not contain the graphs,
but contains all of the other information with the appropriate indicator so
that the report generator displays it or not.
The following table shows the various items that can appear on a report,
depending on the test mode (Auto or Advanced) that is selected.
Item appearing on the report
Auto
mode
Advanced
mode
Summary table: a single table containing the pass/fail
status, the span loss, the span length, and span ORL
for all the wavelengths.
By default, this item is selected.
XX
