Analyzing Traces and Events
122 MAX-700
Selecting the Default View
Note: In Fault Finder mode, only the graph is available.
To select the default view:
1. From the button bar, select OTDR Setup, then the General tab.
2. Under Default view after acquisition, select the desired view.
3. Press Exit OTDR Setup to return to main window.
The application will automatically switch to the selected view when
you perform the next acquisitions.
Summary table
Auto
Advanced
This table gives, for each
wavelength, the pass/fail status of
the results, the span loss and span
ORL values. Span length is also
displayed.
If you purchased the Auto
Diagnostic (AD) software option,
information on macrobends will be
displayed.
For more information, see Summary
Table on page 112.
