Exmark VERTEX X Series User Manual

Specications
X-Series
Dri v e
Pneumatic (Air -Filled)
52 Inch
Models
60 Inch
Models
72 Inch
Models
Quantity
2 2 2
T read
Hoosier
Grassmaster
Hoosier
Grassmaster
Hoosier
Grassmaster
Size 24 x 9.0-12 24 x 12.0-12 24 x 12.0-12
Ply Rating
4 4 4
Pressure
13 psi
(90 kP a)
13 psi
(90 kP a)
13 psi
(90 kP a)
Cutting Deck
• Cutting Width:
– 48 inc hes (121.9 cm)
– 52 inc hes (132.1 cm)
– 60 inc hes (152.4 cm)
– 72 inc hes (182.9 cm)
• Disc harg e: Side
• Blade Size: (3 ea.):
– 48 Inc h Models: 16.25 inc hes (41.3 cm)
– 52 Inc h Models: 18.00 inc hes (45.7 cm)
– 60 Inc h Models: 20.50 inc hes (52.1 cm)
– 72 Inc h Models: 24.50 inc hes (62.2 cm)
• Blade Spindles: Solid steel spindles with 1.00 inc h
(25.4 mm) I.D . bearings .
• Dec k Dri v e:
– Electric clutc h mounted on engine shaft.
– Blades dri v en b y one belt (w/self-tensioning
idlers).
• Number of anti-scalp rollers:
– 48 and 52 Inc h Models: 3 anti-scalp rollers .
– 60 Inc h Models: 4 anti-scalp rollers .
– 72 Inc h Models: 6 anti-scalp rollers
• Dec k: Full oating dec k is attac hed to suppor t
frame , remo v able for ser vice . Dec k design allo ws
for bag ging, m ulc hing or side disc harg e .
• Dec k De pth: 5.5 inc hes (14 cm)
• Cutting Height Adjustment: All models adjusts
from 1.5 inc h (3.8 cm) to 5 inc hes (12.7 cm) in
1/4 inc h (6.35 mm) increments .
• Mulc hing Kit: Optional
• Bag g er : Optional
Dimensions
Overall W idth:
48 Inch
Models
52 Inch
Models
(S-Series)
52 Inch
Models
(X-Series)
Deector
Up
53.25 inc hes
(135.3 cm)
58.08 inc hes
(147.5 cm)
61.66 inc hes
(156.6 cm)
Deector
Do wn
60.05 inc hes
(152.5 cm)
64.79 inc hes
(164.6 cm)
64.79 inc hes
(164.6 cm)
60 Inch
Models
(S-Series)
60 Inch
Models
(X-Series)
72 Inch
Models
Deector
Up
61.38 inc hes
(155.91 cm)
63.76 inc hes
(161.9 cm)
73.43 inc hes
(186.5 cm)
Deector
Do wn
72.87 inc hes
(185.09 cm)
72.87 inc hes
(185.09 cm)
84.84 inc hes
(215.5 cm)
Overall Length:
X-Series
52 Inch Models 60 Inch Models 72 Inch Models
70.45 inc hes
(178.9 cm)
73.37 inc hes
(186.3 cm)
77.12
(195.9 cm)
S-Series
48 Inch Models 52 Inch Models 60 Inch Models
65.33 inc hes
(165.9 cm)
65.33 inc hes
(165.9 cm)
68.24
(173.3 cm)
Overall Height:
• X-Series: 48.9 inc hes (124 cm)
• S-Series: 49.2 inc hes (125 cm)
18
