Maintenance
3. R e place thigh pad.
4. Dri v e the mac hine and c hec k the full forw ard
trac king .
5. R e peat ste ps 1 through 4 until desired trac king
is obtained.
Note: T he motion control lev er needs to be in
neutral while making any necessar y adjustments .
Motion Control Neutral Lock
Adjustment
T here is a plate under the control panel that eng ag es
notc hes in the motion controls when the brak e is
applied in neutral. If the parking brak e plate tabs do
not eng ag e these notc hes , adjust the front control
links .
1. Slo wly apply the brak e while obser ving the tabs
of the brak e plate eng aging the notc hes in the
motion controls . T he loc k plate should drop
easily and freely into the notc hes on eac h side .
2. Chec k that controls are in neutral. Adjust eac h
side via the front control link (see Figure 33 ).
g446989
Figure 33
1. Link 2. Jam nut
3. R emo v e the thigh pad.
4. Loosen upper and lo w er jam n uts at the top of
the front control link.
A. Lengthen link to mo v e control rearw ard.
B . Shor ten link to mo v e control forw ard.
5. P ar tially cycle brak e on and off to obser v e plate
mo v ement in and out of notc h.
6. Tighten jam n uts .
7. R e place thigh pad.
8. Chec k full forw ard trac king .
52
