Exmark VERTEX X Series User Manual

Specications
Specications
Systems
Engine
• Engine Specications: See y our Engine Owner’ s
Man ual
• Engine Oil T ype: Exmark 4-Cycle Premium
Engine Oil
• RPM: Full Speed:
– X-Series: 3600±50 RPM (No Load)
– S-Series: 3700+75/-0 RPM (No Load)
Fuel System
• Capacity:
– X-Series: 14.0 g al. (53 L)
– S-Series: 8.0 g al. (30 L)
• Fuel R ecommendations:
– F or best results , use only clean, fresh, unleaded
g asoline with an octane rating of 87 or higher
((R+M)/2 rating method).
– Oxyg enated fuel with up to 10% ethanol or
15% MTBE b y v olume is acce ptable .
– Do Not use ethanol blends of g asoline (suc h
as E15 or E85) with more than 10% ethanol
b y v olume . P erfor mance problems and/or
engine damag e ma y result whic h ma y not be
co v ered under w ar ranty .
– Do Not use g asoline containing methanol.
– Do Not store fuel either in the fuel tank or
fuel containers o v er the winter unless a fuel
stabilizer is used.
– Do Not add oil to g asoline .
• Fuel Filter : R e placeable In-line
Electrical System
• Charging System: Flywheel Alter nator
• Charging Capacity:
– K a w asaki:
◊ X-Series EFI Models: 30 Amp
◊ All S-Series Models and X-Series Non-EFI
Models: 15 Amp
– K ohler : 20 Amp
• Batter y T ype: BCI g roup U1
• Batter y V oltag e: 12 V olt
• P olarity: Neg ati v e Ground
• Fuses:
– 20 amp c harging system fuse
– 15 amp accessor y fuse
– 20 amp po w er fuse
• Lo w V oltag e Light/Er ror Messag e: Center of
control panel (EFI Models Only)
• Clutc h Sa v er (X-Series EFI Models Only): Allo ws
the throttle to automatically reduce engine RPM
when the PTO switc h is eng ag ed/diseng ag ed or
when ste pping off the platfor m. Engine RPM will
resume its setting when ste pping bac k onto the
platfor m and resetting the PTO .
Safety Interlock System
• LCD indicators appear for the park brak e , PTO ,
Neutral, and operator presence in the messag e
displa y on the front control panel.
• PTO m ust be diseng ag ed with motion control
lev ers in the neutral position and park brak e
eng ag ed to star t the engine . (It is not necessar y
for the operator be on the platfor m in order to
star t the engine .)
Note: T he PTO Eng ag ement Switc h operates
differently betw een the X- and S-Series models
(refer to PT O Enga gement Switch ( pag e 22 ) ).
• Mo w er blades will stop if operator ste ps off the
platfor m.
Operator Controls
Steering Control: Fing er tip dri v e control lev ers
pro vide inde pendent speed control, braking and
neutral to eac h dri v e wheel for mo ving forw ard or
rev erse , stopping, and po w er tur ning .
16
