Exmark VERTEX X Series User Manual

Maintenance
Check Engine Starting Circuit Chart
Note: In the Check Engine Star ting Circuit Char t , the state of system item that is bold is being c hec k ed
in eac h scenario .
X- and S-Series
System
P ar king
Brak e
PT O (Blades)
Motion Contr ol Lev er s Operator Outcome
Disenga ged
Diseng ag ed
In neutral On platfor m
or off the
platfor m
Star ter m ust
not crank
State of
System
Eng ag ed Diseng ag ed
* Lev er s not in neutral
both lev ers mo v ed forw ard or
rearw ard, or either right or left
lev er mo v ed forw ard or rearw ard
On platfor m
or off the
platfor m
Star ter m ust
not crank
State of
System
*Note: First diseng ag e the parking brak e , mo v e the motion controls out of neutral, re-eng ag e the parking
brak e , then contin ue c hec king the scenario .
