Extreme Networks ExtremeSwitching X690 Series User Manual

Table 31: Port Number Assignments (in 40 Gb Mode) (continued)
Physical Port
Number (on
Switch)
Has these Assigned Port Number(s).... ...with this Port Speed
69-72 69 40 Gb
69,70,71,72 10 Gb
Table 32: Port Number Assignments (in 100 Gb Mode)
Physical Port Number (on
Switch)
Has these Assigned Port
Number(s)....
...with this Port Speed
57-60 57 100 Gb
57,59 50 Gb
57,58,59,60 25 Gb
61-64 61 100 Gb
61,63 50 Gb
61,62,63,64 25 Gb
65-68 65 100 Gb
65,67 50 Gb
65,66,67,68 25 Gb
69-72 69 100 Gb
69,71 50 Gb
69,70,71,72 25 Gb
Note
See the ExtremeXOS 30.7 User Guide and the ExtremeXOS 30.7 Command Reference Guide
for feature-specific information about the switches and for information regarding switch
configuration.
ExtremeSwitching X690-48t-2q-4c Switch Ports and Slots
The ExtremeSwitching X690-48t-2q-4c switch ports and slots include:
• 48 fixed autosensing 10GBASE-T ports (ports 1-48) that provide 10 Gbps copper connectivity.
• Two 40-gigabit Ethernet ports capable of supporting passive copper QSFP+ and active
fiber QSFP+
and configurable for 1x40 Gb or 4x10 Gb Ethernet mode.
• Four 100-gigabit Ethernet ports capable of supporting passive copper QSFP28/QSFP+ and active
fiber QSFP28/QSFP+ and configurable for 100 Gb, 40 Gb, 2x50 Gb, 4x25 Gb, and 4x10 Gb modes.
For information about QSFP28 and QSFP+ optical modules, see the Extreme Networks Pluggable
Transceivers Installation Guide.
• Ethernet management port (10/100/1000BASE-T).
ExtremeSwitching Switches
ExtremeSwitching X690-48t-2q-4c Switch Ports and
Slots
ExtremeSwitching Hardware Installation Guide 103
