Table 16: Additional Port LED Meanings for PoE Switches
Label or Type Color/State Meaning
All front panel ports 1-24
or 1-48
Steady green Link is OK; port is not powered
Steady amber Link is OK; port is powered; no trac
Blinking green Link is OK and transmitting packets; port is
not powered
Blinking amber Link is OK and transmitting packets; port is
powered
Slow blinking amber No link, or disabled port; port is powered
Alternating amber and
green
Port has a power fault
O Port is not powered, has no link, or is disabled
Table 17 describes the meanings of the two-digit stack number indicator on all X460-G2 series switches.
Table 17: X460-G2 two-digit Stack Number Indicator
Label or Type Color/State Meaning
Left digit (1) Reserved for future use
Right digit (1 – 8) Indicates the position of this switch in the SummitStack configuration
Upper half blinking This switch is the stack master node
Lower half blinking This switch is the stack backup node
Lit steadily This switch is a standby node in the stack
ExtremeSwitching X465 Series Switches
The X465 series switches provide 24 or 48 Ethernet ports that can be deployed in either Enterprise LAN
or high-density, top-of-rack high-performance enterprise and aggregation applications. In addition,
some models oer either 24 or 48 PoE+ ports.
The 10/100/1000BaseT ports on the X465-24W/48T/48P/48W/24MU-24W models can operate in half-
duplex mode when operating at 10Mbps or 100Mbps. In addition, these models support IEEE 802.1AE
MACsec.
The X465 series switches include the following base models:
• ExtremeSwitching X465-24MU Switch Ports and Slots on page 77
• ExtremeSwitching X465-24MU-24W Switch Ports and Slots on page 78
• ExtremeSwitching X465-24S Switch Ports and Slots on page 78
• ExtremeSwitching X465-24W Switch Ports and Slots on page 78
• ExtremeSwitching X465-24XE Switch Ports and Slots on page 79
• ExtremeSwitching X465-48P Switch Ports and Slots on page 79
ExtremeSwitching X465 Series Switches
ExtremeSwitching Switches
74 ExtremeSwitching Hardware Installation Guide
