Location Speed LED
Indication
Color/State Description
LED
Partitionable
Ports 51-54,
56-59
50 Gbps
(partitioned)
51, 53
Solid green (1, 3)
(2, 4 - O)
The port has link
Blinking green Port is transmitting
or receiving
10/25Gbps
(partitioned)
Solid green (1, 2, 3,
4)
The port has link
Blinking green (1, 2,
3, 4)
Port is transmitting
or receiving
40 Gbps/
100Gbps (no
partition)
Solid green (1)
(2, 3, 4 - O)
The port has link
Blinking green (1)
(2, 3, 4 - O)
Port is transmitting
or receiving
All O or Not Present O No link or port
disable
Note
Each QSFP port that can be partitioned has four LEDs.
ExtremeSwitching X870 Series Switches
The X870 series switch is a 100 Gb switch suited for large datacenter applications. Front-panel Ethernet
ports can provide 100-gigabit Ethernet connectivity using installable QSFP28 and QSFP+ optical
modules. The ports can operate in 40- or 100-gigabit mode and can be partitioned into 10-, 25-, and 50-
gigabit data lanes. (See Partitioning X870 Switch Ports into Data Lanes on page 112 for details and an
example.)
The X870 provides latency less than 600 nanoseconds and supports cut-through switching to help
optimize high frequency trading applications as well as latency sensitive cluster computing.
Native stacking with other X870 series switches is supported using the front panel-ports.
The X870 series includes the following base models:
• ExtremeSwitching X870-32c Switch Ports and Slots on page 114
• ExtremeSwitching X870-96x-8c Switch Ports and Slots on page 115
X870 series switches require ExtremeXOS version 22.2.1 or later.
Partitioning X870 Switch Ports into Data Lanes
Front-panel ports on X870 series switches can be
configured for either 100-gigabit or 40-gigabit mode,
and each port can be partitioned into data lanes through the use of split cables. This yields a total of up
to 128 ports.
ExtremeSwitching X870 Series Switches
ExtremeSwitching Switches
112 ExtremeSwitching Hardware Installation Guide
