Figure 137: VIM5-4X Versatile Interface Module
Table 65: Port Numbers for Ports on the VIM5-4X Module
ExtremeSwitching X465
Port Number for 24-port Models
ExtremeSwitching X465
Port Number for 48-port Models
25-28 49-52
VIM5-4XE Versatile Interface Module
The VIM5-4XE versatile interface module provides four 10-GbE (SFP+) ports, LRM/MACsec capable.
For information about the supported optical modules, refer to the most recent version of the Extreme
Hardware/Software Compatibility and Recommendation Matrices.
Expansion Modules
VIM5-4XE Versatile Interface Module
ExtremeSwitching Hardware Installation Guide 155
