Table 5: X435 System LEDs (continued)
LED Color/State Port State
System Blinking Green System Normal
O System o
Table 6: X435 Port LEDs
Color/State Port State
Solid green Link is OK
Blinking Green Trac activity
Solid Amber PoE and link is up
Blinking amber Link is OK and transmitting packets; port is powered
O No link, or disabled port; port is powered
Table 7: X435-8P-2T-W PD Powered Port LEDs (Ports 9 and 10)
Color/State Port State
Solid green Link is up, not receiving POE power
Blinking Green Trac activity, not receiving POE power
Solid Amber Link is up, receiving POE power, no trac
Blinking amber Link is up, receiving POE power, trac activity
O Link is down and not receiving POE power
Table 8: X435 2.5G Port LEDs (future capability)
Color/State Port State
Solid green Link is up
Blinking Green Trac activity
O Link is down
ExtremeSwitching X440-G2 Series Switches
The ExtremeSwitching X440-G2 switches are cost-eective campus edge switches. They provide 12, 24,
or 48 Ethernet ports that deliver high-density fast Ethernet or Gigabit Ethernet connectivity using fixed
10/100/1000BASE-T ports or 100/1000 BASE-X ports. In addition, some models oer IEEE 802.3at PoE
+ ports.
Note
An extended-temperature model, 24fx-GE4, provides 24 ports of 100Base-FX. Another
extended-temperature model, 12t8fx-GE4, provides 12 ports of 10/100/1000BASE-T and eight
ports of 100Base-FX.
ExtremeSwitching Switches ExtremeSwitching X440-G2 Series Switches
ExtremeSwitching Hardware Installation Guide 29
