Table 15: X460-G2 Front Panel LEDs (continued)
Label or Type Color/State Meaning
S1, S2 (Stack
Management)
Steady green Link OK on the indicated stacking port
Blinking green Activity on the indicated stacking port
FAN Steady green Normal operation
Blinking amber Failure
O No power
P1, P2
(Power Supply)
Steady green Normal operation
Steady amber Non-PoE models: PSU present, but no input
power
PoE models: Not supported
Blinking amber Power failure
O No power is attached
Ethernet Port 1-32 or 1-52 Steady green Link OK
Blinking green Activity on the indicated port
O No link or port disabled
1G SFP ports or 10G SFP+
ports 29, 30, 31, and 32 or
53, 54, 55, and 56
Steady green Link OK
Blinking green Activity on the indicated port
O No 1G or 10G link, or port disabled
Table 16 on page 74 describes the meanings of additional port LEDs on the following X460-G2 PoE
switch models:
• X460-G2-24p-GE4
• X460-G2-24p-10GE4
• X460-G2-48p-GE4
• X460-G2-48p-10GE4
ExtremeSwitching Switches
ExtremeSwitching X460-G2 Series Switch LEDs
ExtremeSwitching Hardware Installation Guide 73
