X2^ = Wattage Power usage in 0.1 watt increments. Example: 260 = 26.0 watts
X2& = Power supply status 0 = Ok 1 = Not Ok
X2* = AESC digital channel pair 1 (default) or 2
X2( = AESG digital channel group 1 (default) or 2
X3) = Input video source 0 = Auto
1 = Video 4 = YUV interlace
2 = S-video 5 = RGB
3 = RGBcvS (SCART) 6 = YUV
X3! = Detected video format 0 = no signal detected
1 = Video 4 = YUV interlace
2 = S-video 5 = RGB
3 = RGBcvS (SCART) 6 = YUV
X3@ = Picture adjustments 000 through 255 (128 = default)
X3# = Shift 0 through 65535
X3$ = Analog input preset 1 through 8
X3% = Output audio source 0 = Original HDMI audio 1 = Embed audio
X3^ = HDCP status (for outputs) 0, 2, 4, or 6 = No monitor connected
1, 3, or 5 = Monitor connected but the video signal is not encrypted
7 = Monitor connected and the video signal is encrypted
X3& = Volume adjustment range 00 – 64 (1 dB per step except for 0-to-1, which is 13 dB) (see table 10 on page 103)
X3* = Digital and analog audio mute status 0 = No mutes (default) 2 = Analog audio mute
1 = Digital audio mute 3 = Analog and digital audio mute
X3( = Video and audio mute status 0 = No mutes (default) 4 = Analog audio mute
1 = Video mute 5 = Video and analog audio mute
2 = Digital audio mute 6 = Digital and analog audio mute
3 = Video and digital audio mute 7 = Video. digital audio, and analog audio mute
X4) = Relay on endpoint 1 or 2
X4! = Pulse duration 0 through 65535 (each step = 16 ms, see the Example on page 107)
X4@ = Relay status 0 = Off 1 = On
X4# = Test pattern 00 = Disable (default)
01 = Color bars, 720p at 50 Hz 07 = Color bars and audio, 720p at 50 Hz
02 = Black field, 720p at 50 Hz 08 = Black field and audio, 720p at 50 Hz
03 = Color bars, 720p at 60 Hz 09 = Color bars and audio, 720p at 60 Hz
04 = Black field, 720p at 60 Hz 10 = Black field and audio, 720p at 60 Hz
05 = Color bars, 1080p at 60 Hz 11 = Color bars and audio, 1080p at 60 Hz
06 = Black field, 1080p at 60 Hz 12 = Black field and audio, 1080p at 60 Hz
X4$ = Name 12 characters maximum
upper- and lower-case alphanumeric characters and _ / and spaces are valid.
NOTE: The HTML language reserves certain characters for specific functions (see Special Characters on page 118).
X4% = Lock mode 0 = Mode 0 1 = Mode 1 2 = Mode 2 (default)
X4^ = Number of inputs 4, 8, 12, 16, 20, 24, 28, 32, 36, 40, 44, 48, 52, 56, 60, or 64
X4& = Number of outputs 4, 8, 12, 16, 20, 24, 28, 32, 36, 40, 44, 48, 52, 56, 60, or 64
X4* = Installed input board F = XTP CP 4i VGA N = XTP CP 4i Fiber 4K
G = XTP CP 4i (TP) P = XTP CP 4i 3G-SDI
H = XTP CP 4i HDMI S = XTP CP 4i HD 4K PLUS
I = XTP CP 4i DVI Pro X = No board installed
X4( = Installed output board D = XTP CP 4o (TP) M = XTP CP 4o SA (stereo audio)
E = XTP CP 4o HDMI O = XTP CP 4o Fiber 4K
J = XTP CP 4o DVI Pro T = XTP CP 4o HD 4K PLUS
X = No board installed
X5) = Firmware version number to second decimal place (x.xx)
X5! = Verbose firmware version-description-upload date/time (see the Query firmware version (verbose) command on page 114).
X5@ = Voltage Positive or negative voltage and magnitude
X5# = Internal temperature Degrees Fahrenheit
X5$ = Fan speed RPM
X5% = Power supply installation status 0 = No power supply installed 1 = Power supply installed
XTP II CrossPoint 1600, 3200, and 6400 Switchers • Programming Guide 85
