RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP5000 High Definition Card Printer/Encoder User Guide (Rev. 1.4)
8-87
Selecting the Lamination Type
Step Procedure
1 Select one of the Lamination Type options, according to which type of
Lamination media is currently installed. Two types of overlaminates are
supported by the Driver: Film Lamination and PolyGuard Lamination.
Custom versions of each type are also available.
• Select the Clear Film Lamination option if the Thermal Transfer Film
Overlaminate type is installed in the Lamination Module.
• Select the 0.6 PolyGuard Lamination option or 1.0 PolyGuard
Lamination option for either patch thickness. (Note: These require
different heat settings and Lamination speeds. Select the appropriate
option according to the thickness of the PolyGuard material you are
using.)
• Select Registered Film Lamination if you have a registered thermal
transfer film.
• PolyGuard Alternating Patch and Holographic Film Lamination
are options.
